Larger energy capacity
Longer cycle life
Lighter weight
High power
Wider temperature range
Superior Safety
Accurate power calculation
Application: Household energy storage,
outdoor power supply .etc
Model | LFP48100 | LFP48150 | LFP48200 | LFP51.2100 | LFP51.2150 | LFP51.2200 |
Electrical Parameter | ||||||
Rate voltage | 48V | 51.2V | ||||
Rate capacity | 100AH | 150AH | 200AH | 100AH | 150AH | 200AH |
Energy | 4800Wh | 7200Wh | 9600Wh | 5120Wh | 7680Wh | 10240Wh |
Cycle life | > 4000 cycles 80% DOD | |||||
Internal Impedance | ＜50 mΩ | |||||
Designed life | 10 Years | |||||
Operating Parameter | ||||||
Charge voltage | 53.2V | 56.8V | ||||
Charge current | 50A | 75A | 100A | 50A | 75A | 100A |
Max.Charge current | 100A | 100A | 100A | 100A | 100A | 100A |
Discharge cut-off voltage | 37.5V | 40V | ||||
Discharge current | 50A | 75A | 100A | 50A | 75A | 100A |
Max.Discharge current | 100A | 100A | 100A | 100A | 100A | 100A |
Discharge temperature | -20~55℃ | |||||
Charge temperature | 0~55℃ | |||||
Storage temperature | -10~45℃ | |||||
Function items | ||||||
Parallel Connection | Max 15P | |||||
Communication Port | RS485 / CAN / Dry contact | |||||
SOC display | LED | |||||
Optional items | ||||||
Display | LCD | |||||
Manchanical Parameter | ||||||
Terminal | M8 / Connector | |||||
Weight | 43KG | 69KG | 78KG | 44KG | 70KG | 79KG |
Dimension(Wx D x H)mm | 445x430x132 | 445x560x177 | 445x560x222 | 445x430x132 | 445x560x177 | 445x560x222 |
Protection | IP20 | |||||
Standard | ||||||
Certification | CE | |||||
