Larger energy capacity
Longer cycle life
Lighter weight
High power
Wider temperature range
Superior Safety
Accurate power calculation
Application: Data room, power grid-
connected and off-grid, large-scale energy storage .etc
Model | LFP192100 | LFP192200 |
Electrical Parameter | ||
Rate voltage | 192V | |
Rate capacity | 100AH | 200AH |
Energy | 19.2KWh | 38.4KWh |
Cycle life | > 4000 cycles 80% DOD | |
Designed life | 10 Years | |
Operating Parameter | ||
Charge voltage | 213V | |
Charge current | 50A | 100A |
Max.Charge current | 100A | 200A |
Discharge cut-off voltage | 150V | |
Discharge current | 50A | 100A |
Max.Discharge current | 100A | 200A |
Discharge temperature | -20~55℃ | |
Charge temperature | 0~55℃ | |
Storage temperature | -10~45℃ | |
Function items | ||
Communication port | RS485 / CAN | |
Display | LCD | |
Manchanical Parameter | ||
Terminal | Anderson / Connector | |
Weight | 180KG | 355KG |
Dimension(Wx D x H)mm | 440x650x170mm (12U) | 440x650x170mm(24U) |
Protection | IP20 | |
Standard | ||
Certification | CE | |
