Larger energy capacity
Longer cycle life
Lighter weight
High power
Wider temperature range
Superior Safety
Accurate power calculation
Application: Data room, power grid-
connected and off-grid, large-scale energy storage .etc
Model | LFP48040 | LFP48080 | LFP480120 | LFP48040*N |
Electrical Parameter | ||||
Rate voltage | 480V | |||
Cluster | 1 | 2 | 3 | N |
Adjustable rate voltage | 384V / 480V / 499.2V / 528V | |||
Rate capacity | 40AH | 80AH | 120AH | 40AH*N |
Energy | 19.2KWh | 38.4KWh | 57.6Wh | 19.2KWh*N |
Cycle life | > 3000 cycles 80% DOD | |||
Designed life | 10 Years | |||
Operating Parameter | ||||
Charge voltage | 532V | |||
Adjustable charge voltage | 426V / 532V / 553V / 585V | |||
Charge current | 40A | 80A | 120A | 40A*N |
Max.Charge current | 80A | 160A | 240A | 80A*N |
Discharge cut-off voltage | 375V | |||
Adjustable discharge cut-off voltage | 300V / 375V / 390V / 412V | |||
Discharge current | 80A | 160A | 240A | 80A*N |
Max.Discharge current | 160A | 320A | 480A | 160A*N |
Discharge temperature | -20~55℃ | |||
Charge temperature | 0~55℃ | |||
Storage temperature | -10~45℃ | |||
Function items | ||||
Communication port | RS485 / CAN | |||
Display | LCD | |||
Manchanical Parameter | ||||
Terminal | Anderson / Connector | |||
Weight | 280KG | 560KG | 840KG | 280KG*N |
Dimension(Wx D x H)mm | 440x630x132mm(21Ux1P) | 440x630x132mm(21Ux2P) | 440x630x132mm(21Ux3P) | 440x630x132mm(21UxNP) |
Protection | IP20 | |||
Standard | ||||
Certification | CE | |||
